DIDECK Series

Mechanical Feature: High-strength translucent panel

Steel plate matching: Matched with normal Al-Zn alloy coated steel sheet

Resin Components: Improved ageing-resistant SMR199 resin

Fiber Reinforcing: Alkali-free roving glass fiber

Surface Treatment: Normal ageing-resistant covered by Dupont Melinex301 weather-resistant films and 30μm R-Class gel-coat

Reinforcing Tensile Strength: vertical tensile reinforced fibers on inner surface

Glass Fiber: Not less than 28%

Unit Weight: 1800g/m², 2400 g/m², 3050 g/m²

Standard thickness: 1.2mm, 1.5mm, 2.0mm (with tolerance ≤10%)

Recommended Service Temperature: -60℃ to +130℃

Light Transmission: 1.5mm: 72%±2% (green-water、light blue or fog-white), 52%±2% (milky white)

UV Resistance: 99%

Tensile Strength: 90Mpa

Flexural Strength: 160Mpa

Breaking Expansion Ratio: 1.9%

Thermal Co-efficient: 2.5~3.2×10^-5/K

Warranty: 20 years
